Zortrax M300 Plus

Zortrax M300 Plus 3D Printer

The Zortrax M300 Plus is a large-format FDM 3D printer designed for industrial use. With a build volume of 300 x 300 x 300 mm, this printer is ideal for printing large models or small series production in one go. The M300 Plus is characterized by its reliability, user-friendliness, and compatibility with a variety of filaments, including demanding materials such as TPU and Nylon.

Technical Data Features Details Build Volume 300 x 300 x 300 mm Printing Technology LPD (Layer Plastic Deposition) Nozzle Diameter 0.4 mm (standard), 0.3 mm / 0.6 mm optional Extruder Single extruder (compatible with flexible materials) Printing Temperature (Max.) 290 °C Print Bed Temperature (Max.) 105 °C Connectivity Wi-Fi, Ethernet, USB Touchscreen 4-inch IPS display Filament Diameter 1.75 mm Camera Built-in for remote monitoring Layer Thickness 90 - 390 microns Software Z-SUITE (supports .stl, .obj, .dxf, .3mf, .ply formats) Main Features

• Large Build Volume: With 300 x 300 x 300 mm, the Zortrax M300 Plus allows printing large models in a single pass without the need to assemble parts.
• Advanced Material Compatibility: Compatible with a wide range of materials, including demanding filaments like Nylon and TPU.
• Wi-Fi and Ethernet: The printer can be integrated into 3D printing farms and operated remotely, ideal for mass production.
• User-Friendly Control: The intuitive user interface and semi-automatic leveling simplify the printing process.
• Integrated Camera: Monitor your print projects in real time thanks to the built-in camera.

User Benefits

• Reliability in Continuous Operation: The M300 Plus is optimized for long print cycles and offers high reliability for industrial applications.
• Easy Operation: Thanks to plug-and-play functionality and an easy-to-understand control, even less experienced users can get started quickly.
• Material Flexibility: Supports both Zortrax and third-party filaments, increasing adaptability for various projects.
