Liqcreate Bio-Med Clear

Liqcreate Bio-Med Clear – Transparent, biocompatible resin for medical and wearable prototypes

Liqcreate Bio-Med Clear is a transparent, rigid photopolymer resin specially developed for use in DLP, LCD/MSLA, and laser-based 3D printers in the wavelength range of 385–420 nm.
In combination with the validated cleaning and curing process, it meets the requirements of ISO 10993-5, -10 and -23 regarding cytotoxicity, sensitization, and skin irritation. This makes it ideal for medical applications as well as prototypes requiring skin or body contact.

Key features

• Biocompatible after validated washing & curing process

• Autoclavable and resistant to common disinfectants

• High dimensional accuracy for precise fits

• Transparent, rigid components for visualization and flow testing

• Compatible with 385–420 nm DLP, LCD/MSLA, and laser systems

• Validated print parameters available, including for Raise3D DF2

Precision and stability

The combination of high dimensional accuracy and shape stability enables precise fit testing as well as the production of transparent housings and components for flow testing. Thanks to the clear optics, internal structures and fluid paths can be optimally assessed.

Validated workflow for consistent quality

To achieve the specified biocompatible properties, it is important to follow the recommended process from printing through cleaning to final curing. Manufacturer-documented parameters help ensure reproducible results.

Sterilization options

After proper post-processing, components can be cleaned with common disinfectants or sterilized by steam autoclaving. This facilitates use in realistic, hygienically demanding test environments.

Typical areas of application

• Medical and wearable prototypes

• Custom fixtures, gauges, and guides

• Transparent housings and mounts

• Functional prototypes with clear optics and precise fit
