E3D Revo High Flow High Temp Abrasive Nozzles – up to 500 °C, wear-resistant

E3D RapidChange Revo High Flow High Temp Abrasive (HF HT-A) nozzles are the ideal choice for high-temperature and high-flow printing with abrasive filaments. Thanks to robust materials and optimized heat transfer, they deliver reliable results even under extreme conditions up to 500 °C.

Highlights:

• Copper/steel construction with chromium nitride coating
• Heat resistant up to 500 °C (with Revo High Temp Hotside Kit)
• High flow rates for faster printing
• Wear-resistant – ideal for abrasive filaments
• Simple, tool-free nozzle changes
• Available sizes: 0.4 / 0.6 / 0.8 / 1.0 / 1.2 / 1.4 mm

Features & Benefits:

The HF HT-A nozzles combine a hardened steel nozzle with a copper carrier and distributor, achieving excellent heat transfer. The chromium nitride coating additionally protects against abrasion, corrosion, and filament sticking. The High Flow design significantly increases the melt rate – perfect for large-volume or fast prints with technical materials.

Application areas:

• Printing with abrasive filaments (e.g., carbon fiber-, glass fiber-, or metal-filled)
• High-temperature materials up to 500 °C (e.g., PEEK, PEKK, PSU)
• Large-format prints with high flow rate
• Prototyping and functional end parts

Compatibility:

Compatible with E3D RapidChange Revo Hotends. The nozzles have the same design as standard Revo nozzles, so no adjustments to the fan duct or mount are required. Note: Limited to 300 °C with 40W and 60W HeaterCores. For up to 500 °C, a Revo High Temp Hotside Kit is required. Not compatible with V6 HeaterBlocks.

Advantage RapidChange:

Each Revo nozzle is pre-assembled (nozzle + HeatBreak in one piece) – no hot tightening, no risk of leaks. Sizes are clearly engraved and easily identifiable.
